1 Scope

1.1 These requirements cover the battery-operated electrical systems that use consumables containing varying compositions of flavorings, propylene glycol, glycerin, and other ingredients, with or without nicotine, which is heated into an aerosol that the user inhales. Examples include but are not limited to vaporizers, vape pens, hookah pens, e-hookah, e-shisha, e-pipes, electronic cigarettes, e-cigarettes and electronic nicotine delivery systems (ENDS). These systems encompass their charging systems, components, parts and accessories.

1.2 These requirements do not cover the consumables, such as e-liquids and other inhaled aerosol substances, wicks, and other particulate matter inhaled during use, nor do they cover substances in the emissions from the operation of the devices.

NOTE For example, heavy metal emissions in the aerosol and environmental exposure.

1.3 These requirements do not consider the physiological effects of any consumable used with the devices.

Summary of Topics

The revision of ANSI/CAN/UL 8139 dated July 6, 2020 includes the following changes:

Clarification to Section 7.2, Exception applies to Flammability and Mechanical RTI; 7.2, 28.2, 29.4, and 30.2

Clarification to 8.2, Electrochemical Corrosion; 8.2, 8.2A

Add Exception to 9.2 to address inadvertent shorting

Clarification to Section 10.4 to indicate a charging interface needs to be tested

Clarifications to Table 17.1; 17.1, Section 31A

Correction of temperature in Section 22.4

Section 29.6, Clarifying the determination of voltage difference for the drop test

Section 17.4, Removal of potentiometers from temperature measuring

Addition of an alternative specification for cheesecloth; 17.10

Allowing more appropriate discharge test parameters for greater relevance to device parameters; 20.3

Clarification that single fault conditions do not apply to overload test; 25.3

Clarifications to Table 26.2

Clarification to Section 26, Temperature Testing; 26.1, 26.2, 26.4, 26.6

Correction to venting test procedures; 31.1

Addition of performance-based marking durability test; 33.1, 33.1A

Clarification to markings and warnings; 33.7

Imbalanced charging clarifications; 22.2
